High Silicon Cast Iron Anode

Method: Resin
Material: High Silicon Cast Iron





High Silicon Cast Iron Anode

High Silicon Cast Iron

This is a kind of product of cathode protection. Its theory is that connects the current of negative metal material or  alloy with the protected metal body, with the exhausting and dissolving of negative metal material or alloy, protective current is transfused to protected metal body, this metal body will be protected from corrosion.

Features

High silicon cast iron anode is a kind of product of cathode protection.
Applications
Used as strong currency cathode protection in sea, soil, water.



Chemical Composition

Type
Element %
max impurity
Si
Cr
Mn
C
Fe
P
S
 high silicon cast iron anode
14-16
0.6-0.8
0.8-1.05
remainder

<0.25

<0.1
high silicon iron anode with Chromium
14-16
4.0-4.5
0.6-0.8
0.8-1.05
remainder
<0.25
<0.1
